Electron E-ROBOT+3 Series - Ordering Information; Ordering Reciprocator Systems

38
Stroke Lenght [mm] Reciprocator (kg) Case (kg)
2 reciprocators with case-SET (kg)
1200 154 225 533
1500 163 240 566
1800 173 255 601
2100 183 270 636
2400 193 285 671
2700 202 300 704
Horizontal Reciprocator aprx. 250 (with palette)
C) Weight
NOTE:
Reciprocator enclosing dimensions are given so that two single vertical axes fit in the same case.
11.3. Transport
12. Ordering
12.1 Ordering Reciprocator Systems
11.3.1 Data concerning goods to be transported
The space requirements correspond to the size of the axes of motion plus the packaging.
11.3.2 Loading, transferring the load, unloading
At least one fork lift must be available.
1) For a single Reciprocator system;
Systems Products Types Codes Qty
Vertical Axis
Reciprocator
System
E-ROBOT+3 Z
1200 Stroke B07RG0301
1
1500 Stroke B07RG0302
1800 Stroke B07RG0303
2100 Stroke B07RG0304
2400 Stroke B07RG0305
2700 Stroke B07RG0306
E-DRIVE ZX02-E N/A B08ZX02CM-E 1
E-DRIVE ZX02-E RECIPROCATOR SIGNAL
CABLE
10 MT B08ZX02SC-E10
1
15 MT B08ZX02SC-E15
20 MT B08ZX02SC-E20
25 MT B08ZX02SC-E25
E-DRIVE ZX02-E RECIPROCAT
OR POWER
CABLE
10 MT B08ZX02PC-E10
1
15 MT B08ZX02PC-E15
20 MT B08ZX02PC-E20
25 MT B08ZX02PC-E25
