Electron E-ROBOT+3 Series - Page 51

51
D-PART
Part # Order Code Part Name Qty
D-PART B07RBM130
E-DRIVE RECIPROCATOR TOP GEAR SET - COMPLETE
1
10 GAAE02006
INSTALLED TRACTION GEAR
1
11 TRTM06009
TOP GEAR TRACTION PART
2
12 B06RB01034
TOP GEAR TRACTION LOCK PART
2
13 B07RS0005
WELDED TOP GEAR TRACTION SET
1
14 BECV06162
M12X75 EYEBOLT PASO DIN444
2
15 GAAE04019
TOP GEAR TRACTION SCREW
1
16 TRTM06010
Ø17 SCREW RING
1
17 BECV06014
M8X25 COATED BOLT
2
