Electron E-ROBOT+3 Series - Page 57

57
Part # Order Code
Part
Name
18 GAAE02007
TRIGER GEAR Z = 22 BUSH TYPE (12.7 STEP BY Ø18
SHAFT)
1
19
B07500600
ENCODER ROTARY ATEX ZONE 22
1
20
TRTM06034 ROBOT - EX ENCODER CONNECTING SHAFT
1
21 B06RB03041
E-ROBOT+3 Horizontal Axis Gearbox Front Flange 1
22 TRTM03080
E-ROBOT+3 HORIZONTAL AXIS ATEX ENCODER
CONNECTING SHAFT
1
20
22
21
18
19
A2-PART
