7 Technical Data
7.1 Identification
7.1.1 Type Label
The type label serves for the identification of the unit. It is located on the housing of the sensor and gives the
exact type designation (= order reference, see 9) with the corresponding part number. Furthermore, the type
label contains a unique, traceable device number, the production date as well as the hardware and software
versions. When corresponding with ELGO always indicate this data.
Figure 1: Example of a type label for identification of the sensor
7.1.2 Info Label and Info Sheet
Each system is designed for a customer specified configuration ( 14.1). For subsequent transparency of the
respective configuration it is strongly recommended to attach an info sheet Figure 3 with all important settings to
the documentation of the installation. A label with the configuration ID (Figure 2) is attached on the device
housing as well. Additionally, an info sheet with all configuration information should be attached to the elevator
system (e. g. in the shaft).
Figure 2: Example of an info label on the housing with a specific system configuration
Prod.Date:
Version:
ELGO Part No.:
Serial No.:
000000
XX.XXXX MADE IN LIECHTENSTEIN
000000000
LIMAX3CP-00-030-1000-CO0T-1-0
P-0001/250k/0/1
HW: XX.X / SW: X.XXXX
Type Designation ( 9):
Designation 1
Designation 2
