Technical Data
- 15 -
Tripping speeds
Rated speed 1000 mm/s
Pre-tripping speed 1150 mm/s
Final tripping speed 1300 mm/s
Pre-tripping speed teach 700 mm/s
Final-tripping speed teach 1000 mm/s
Pre-tripping speed inspection 600 mm/s
Final-tripping speed inspection 800 mm/s
Features
Trip direction of eSGC („BOTH“/„Only DOWN“) BOTH
UCM acts („only OC“ / „eSGC and OC“) eSGC and OC
Configuration Data
Limit switch offsets (with reference to the shaft ends)
Upper pre-triggered stopping system limit 1200 mm
Lower pre-trigegred stopping system limit 0 mm
Deceleration control
Deceleration a 1.2 m/s
2
Delay of brake 200 ms
Buffer speed 600 mm/s
Upper offset 0 mm
Lower offset 0 mm
Safety functions(enabled/disabled)
Door (bridging + UCM) enabled
Final limit switches enabled
Deceleration control enabled
Over speed pre-tripping enabled
Over speed final-tripping enabled
Over speed teach pre-trip. enabled
Over speed teach fin.-trip. disabled
Working platform disabled
Inspection functions (global) enabled
Over speed insp. fin.-trip. enabled
Upper pre-trigg. stop. System enabled
Lower pre-trigg. stop. System disabled
Actuators (enabled/disabled)
OC enabled
eSGC enabled
SR1 enabled
SR2 disabled
Teach featues (enabled/disabled)
Auto teach disabled
Auto adjust disabled
Figure 3: Example of an info sheet for the documentation of the installation with a specific system configuration
7.1.3 Configuration of the Device
The customer has the choice. He may either order an already configured device at ELGO ( 7.1.3.2), or he
orders a blank device and does the configuration on site.
7.1.3.1 Configuration on site
It is possible to order a blank device at ELGO and do the configuration on site.
In this case same label applies as described in Figure 2, but with blank configuration ID. A sticker with the con-
figuration ID has to be attached onto the info label).
The blank device will be configured with the values / features via CAN-Bus. These can be found on the infor-
mation sheet (Figure 3) in the documentation of the installation. For example, the lift control can be used as
input/display unit for the configuration. In addition to the actual configuration information, the CRC from the
info sheet must be sent to the device.
The LIMAX33 CP-00 will accept the configuration only if the CRC fits. This prevents configuration errors due to
incorrect input or incorrect transmission. After the LIMAX33 CP-00 accepted the configuration it is fixed and it
cannot be changed anymore.
If lift control shall be used as input/display- unit the corresponding features must be implemented.
 refer also to CANopen specification
