Elgo LIMAX33 CP-00 SERIES User Manual

Technical Data
- 17 -
7.3 Technical Data LIMAX33 CP-00
LIMAX33 CP-00 (Standard version)
Mechanical Data
Measuring principle
Absolute
Repeat accuracy
±1 increment
System accuracy in µm at 20°C
±(1000 + 100 x L) L = measuring length in meters
Distance sensor / magnetic tape
the correct distance is guaranteed by guidance
Basic pole pitch
8 mm
Sensor housing material
aluminum
Sensor housing dimensions
L x W x H = 354 x 136 x 54 mm
Necessary magnetic tape
AB20-80-10-1-R-D-15-BK80
Maximum measuring length
260 m
Connections
2 outlets with open wire ends for PIO and SCA cables
(plug connectors on request)
M12 4 pole male for eSGC; according to ICE61067-2-101
Sensor cable (PIO, SCA)
standard length: 3.0 m (others on request)
Weight
approx. 1400 g without cable; cable: approx. 60 g per meter
Electrical Data
Supply voltage
18 ... 30 VDC (stabilized). A SELV/PELV power supply must be used
Residual ripple
< 100 mV
DZO rating
+ 24 VDC −20 %, max.200 mA (push-pull)
Reverse polarity protection
integrated
Power input
max. 600 mA at 24 VDC
Interfaces
CAN: CANopen DS406 or DS417 (others on request)
Digital input voltage
18 … 30 VDC for high level; open for low level
Relay contact rating
OC, SR1, SR2
0 … 230 VAC (max 250 VAC), max. 2 A; or
24 VDC (max. 30 VDC), max. 1 A; or 110 VDC, max. 250 mA;
each with a resistive/inductive load with L/R < 40 ms
Rating for external supply
of SGC-actuator
24 VDC, min. 18 V; max. 30 V; constraints for connected trip coil to be
observed (refer also to chapter 8, topic  23 and  24
Environmental Conditions
Storage temperature
−25 … +85° C
Operation temperature
−20 … +65° C
(−25 … +85° C on request)
Humidity
max. 95 %, non-condensing
Protection class
IP54 (according to EN60529), higher on request
Interference emission / immunity
EN 12015 / EN 12016
Vibration / shock resistance
EN 60068-2-6 / EN 60068-2-27, EN 60068-2-29
Others
Maximum operating time
20 years
Safety relay contact reaction time
< 55 ms
Solid state contact (eSGC) reaction
time
< 45 ms
