Elgo LIMAX33 CP-00 SERIES User Manual

Installation and First Start-Up
- 27 -
Table 3: Floor Sensor plugs
Number of Floor Sensors
Type of electrical Installation
No floor Sensor
No installation necessary
(max.) 2 floor Sensors
In case of LIMAX33 CP-00 with (optional) two floor sensors, there are circular
connectors on the bottom side. Each of them is closed with a protective cap. The
cap must only be removed immediately before the floor sensor is plugged. The
person removing the cap and plugging the floor sensor must be grounded.
Remark: In case floor sensors are used, each floor level must be marked with a floor magnet.
Concerning mechanical installation of floor sensor(s) and magnets refer to the manual of the floor sensors.
Table 4: Earthing lug
The earthing lug on the LIMAX33 CP-00 must be connected to protection earth
10.4.2 Protection against Electrical Shock
For protection against electrical shock by direct contact, the housing of the LIMAX33 CP-00 has a protection
class of IP54.
For protection against electrical shock by indirect contact, the housings of the LIMAX33 CP-00 are equipped
with an earthing lug. This needs to be connected to the protection earth (refer to section  10.4.14).
