Installation and First Start-Up
Before the electrical installation can begin, the complete elevator unit has to be de-energized.
The upper part of Figure 6 shows a view on the LIMAX33 CP-00 housing (including the defi-
nition of the cable assignment, connectors and earthling lug to the designations used in the
following tables).
Table 1: Connections PIO and SCA-Cable
PIO-cable SCA-cable
Inspection direction “UP”
Inspection direction “DOWN”
Remark: The PIO and SCA cable of the LIMAX33 CP-00 have open wire ends by default, so the function is de-
fined by the wire color. Later LIMAX33 CP-00 cable ends may be equipped with plugs due to customer order. In
this case this manual will be extended or a separate document will exist which defines the pin-assignment of the
plugs.
Table 2: eSGC-Connector (only for versions with eSGC)
Ground (reference potential) for External power supply for trip coil of eSGC-
braking-element; to be connected to GND of external power supplly as well
as to the other side of the trip coil.
Switched SG_POW; will be swtiched on if lift movement can be released
concerning to eSGC-actuator, switched off if safe state must be established.
To be connected to one side of the trip coil of eSGC-braking-element.
To be connected to external power supply for trip coil of eSGC-braking-
element; 24 V recommended; SELV/PELV supply required; 30 V must not be
exceeded.
