Elgo LIMAX33 CP-00 SERIES User Manual

Safety Functions
- 72 -
13.4 Safety Functions before Commissioning
The behavior of the safety functions in pre-commissioning mode  11.1 is the same as in trach mode  13.3.
Remark: Reference positions are never available in in pre-commissioning mode.
In pre-commissioning mode 11.1, only the following safety functions are active:
Table 18: Safety functions before commissioning
Name
Norm reference
SIL
Comments
Overspeed (pre-tripping)
EN 81-1 9.9.11.1
SIL2
Same as in normal mode
Overspeed (final-tripping)
EN81-20 §5.6.2.2.1.1a.)
SIL 3
Same as in normal mode
Overspeed teach
(pre-tripping)
Additional function,
no norm reference
SIL3
Same as in teach mode
Overspeed teach
(final-tripping)
Additional function,
no norm reference
No SIL
Same as in teach mode
Inspection
limit switches
EN81-21 §5.5.3.4,/
§ 5.7.3.4
SIL2
Always open (because no references avail-
able in pre-comm. mode) => OC opens
as soon as EN 81-21 state is active.
Supervision on
inspection direction
no norm reference
SIL2
Same as in Normal mode
Pre-triggered
stopping system
EN 81-21 §5.5.2.2 / §5.7.2.2
SIL3
pre-triggered stopping system will
always trip in EN81-21-state
Working platform
EN81-20 §5.2.6.4.3.1 b.)
SIL 3
Same as in normal mode
No door bridging and no UCM are active in pre-commissioning mode.
 SR1 and SR2 are always open in pre-commissioning mode .
