Elgo LIMAX33 CP-00 SERIES User Manual

During Operation
- 54 -
Table 10: Error codes
Meaning of
the
code/group of
codes
Error
codes
Meaning of special
errors
Measures to fix the error
1xxh
Position errors
101h –
115h
Failures in position
The cause for these errors may be.
1. Incorrect mounting
2. The magnetic tape
3. the LIMAX33 CP-00 (electronics)
For troubleshooting 1
st
check the correct mounting of the tape,
tape guiding and LIMAX33 CP-00 (correct up-direction, tape in
the tape-guiding, and so on…)
If this is correct try to replace LIMAX33 CP-00 (electronics), if this
does not help, replace the magnetic tape.
Hint: if the error occurs always about at the same position, it is
more likely that the cause is the tape. If it occurs everywhere over
the whole reading distance it is more likely that the cause is the
LIMAX33 CP-00 (electronics)
34xh
Relays error
340h
There was no Reset or
power cycle for more
than one and a half
year,
Perform a power cycle or a reset (it order to maintain the defined
test-intervals for some diagnostics it is mandatory to perform a
power cycle or reset annually)
34xh
Relay failure
replace LIMAX33 CP-00
35xh
eSGC (solid
state relay)
error
350h
eSGC undervoltage
Check (external) supply voltage of SCG-actuator. If supply is not
connected or voltage too low (<18V), fix it. If this does not help
replace LIMAX33 CP-00
351h
eSGC overvoltage
Check (external) supply voltage of SCG-actuator. If voltage is too
high (>30V), fix it. If this does not help, replace LIMAX33 CP-00
35xh
Other eSGC – errors
Check if trip coil of SCG-actuator is properly connected and
possibly fix the fault concerning the connection. If this does not
help replace LIMAX33 CP-00
37xh
Voltage error
370h
Over/under voltage
external (24V) and/or
internal supply voltage
Check 24 V supply, a voltage of more than 30 V may cause this
error. Rectification: use a supply voltage of 24 V. If this does not
help or supply voltage was not too high, replace LIMAX33 CP-00
37xh
(other
than
370h)
Failure concerning
test of the internal
voltages
replace LIMAX33 CP-00
64xh
66yh
Nonvolatile
data
64xh,
x=3h..Eh
66yh,
y=2h..Dh
Failure concerning
check of nonvolatile
stored data
These errors may appear if the system has been powered down,
while storing of data in the EEPROM was in progress. For more
detailed descriptions und measures to fix the error see Table 11
7xxh
Configuration
700h
Configuration empty
Program the intended configuration to the device
72xh
Failure in program-
ming the configura-
tion (tried to program
an invalid configura-
tion)
Check/correct the configuration to be programmed, try to pro-
gram the configuration again.
72xh
All other failures
concerning the con-
figuration
replace LIMAX33 CP-00
All other
error
codes
Only of inter-
est for repair
at ELGO-plant
All other
error
codes
Only of interest for
repair at ELGO-plant
replace LIMAX33 CP-00
