Configured/settable Parameter and Features
- 74 -
Hint for definition of final-tripping speed inspection:
When the customer defines the offsets for the pre-triggered stopping system limits (see Table 21) he has to take
the braking distance of the car after the safety gear tripped into account. The breaking distance again depends
on the speed. The final tripping speed inspection must be at most as great as the speed assumed when deter-
mining the braking distance.
The speed configuration is only valid, when all of the following rules are met. All of the speeds must be in the
allowed range (defined in the table above).
If V
rated
<= 1 m/s than the V
finaltrip
must be < 1,5 m/s
If V
rated
> 1 m/s than the V
finaltrip
must be
< (1,25 * V
rated
+ 0,25 / V
rated
)
If V
rated
<= 1 m/s than the V
pretrip
must be <= V
finaltrip
If V
rated
> 1 m/s than the V
pretrip
must be < V
finaltrip.
V
pretrip_teach
must be <= V
finaltrip_teach
V
pretrip_inspection
must be <= V
finaltrip_inspection
Furthermore, there are configuration parameters concerning the ETSL-Curve:
Table 20: configuration parameter for ETSL-Curve
Parameter
Value range
Unit
Explanation
a
100 10000
mm/s
2
Deceleration a
t
del
20 500
ms
Delay of the functional chain: from detecting ETSL-event by LIMAX33 CP-00 until
start of deceleration of the car.
V
Buf
0 2500
mm/s
It is sufficient to reduce the speed to that speed the buffers are designed for. This
Value gives the remaining speed when the car hits the buffers provided the car
retards due to deceleration curve defined in the concerning chapter.
Offset
ETSL_UP
0 1000mm
mm
The distance s to the assumptive buffer when moving up is reduced by this offset
Offset
ETSL_down
0 1000mm
mm
The distance s to the assumptive buffer when moving down is reduced by this offset
Furthermore, there are configuration parameters concerning the offsets of the stopping system limits:
Table 21: configuration parameter for offsets of stopping system limits
Parameter
Value range
Unit
Explanation
Offset upper
pre-triggered stop-
ping system limit
0 2500
mm
Determines the position of the upper stopping system limit as an offset to the
highest reference position:
Pos
upper_stopping_system_limit
= Pos
upper_reference
Offfset
upper_stopping_system_limit
Offset lower pre-
triggered
stopping system
limit
0 2500
mm
Determines the position of the lower stopping system limit as an offset to the low-
est reference position:
Pos
lower_stopping_system_limit
= Pos
lower_reference
+ Offset
lower_stopping_system_limit
