Elgo LIMAX33 CP-00 SERIES User Manual

During Operation
- 55 -
Table 11: Errors concerning nonvolatile stored data
Name
Error codes
Measures
Shaft parameter
(offset final limit switch,
offset inspection limit
switch)
1. 0x643
2. 0x644
3. 0x662
4. 0x663
 Go to settings or teach mode.
 Set new shaft parameter or set them to default.
Shaft references
(reference position for the
limit switches)
1. 0x645
2. 0x646
3. 0x664
4. 0x665
 Go to Pre-Commissioned mode.
 Make a power cycle.
 Redo the teach-process.
Floor table
1. 0x647
2. 0x648
3. 0x666
4. 0x667
 Go to Pre-Commissioned mode.
 Make a power cycle.
 Redo the teach-process.
Floor parameter
(number of floors, valid
flag)
1. 0x649
2. 0x64A
3. 0x668
4. 0x669
 Go to Pre-Commissioned mode.
 Make a power cycle.
 Redo the teach-process.
Door parameter
(relevelling zone size,
levelling zone size, mini-
mum distance)
1. 0x64B
2. 0x64C
3. 0x66A
4. 0x66B
 Go to settings or teach mode.
 Set new door parameters or set them to default.
Safety Functions
(state of the safety func-
tions)
1. 0x64d
2. 0x64e
3. 0x66C
4. 0x66D
 Make two system resets.
Legend:
1. CRC mismatch to EEPROM (at initialization)
 This can happen,
 if the store was not successful, caused by power cycle
 or an EEPROM error
2. Channel CRC mismatch (at initialization)
 This can happen,
 if the store was not successful on one channel, caused by power cycle
 or an EEPROM error
3. CRC mismatch to EEPROM (at runtime)
 This can happen,
 if the store was not successful, caused by power cycle (consequence of 1.)
 or an EEPROM error or RAM error
4. Channel CRC mismatch (at runtime).
 if the store was not successful, caused by power cycle (consequence of 2.)
 or an RAM error
