Operation modes and Commissioning
11.6.2 Automatic Adjustment by Floor Sensors
While adjusting, using floor detection sensors, an already known floor in the floor table will be adjusted auto-
matically under the following conditions:
The actual speed is less than 1 m/s
A floor sensor (first or second side) detects a floor which already exists in floor table. This means: The
distance of the actual position to nearest floor position with a door existing on the side corresponding
to the floor sensor is smaller than ±50 mm
The new position (after adjustment) of the floor must be within ±100 mm related to its original position
The distance of the actual position to nearest floor position in the floor table on the corresponding side
is bigger than ±5 mm.
In case of double side floors, the 1
st
side floor position takes the leadership: only the position of front
side is taken into account concerning the adjustment.
The adjustment must not change the ascending floor ordering.
If all conditions above apply, the actual position will be stored as the new position of the corresponding floor in
the floor table. Otherwise the detected floor is ignored and floor table will not be changed.
Automatic adjustment by floor sensors will be carried out in normal-, settings-, test- and teach-mode (regardless
of the sub-modes). Automatic adjustment by floor sensors will not be carried out if is not enabled in the configu-
ration 14.1.5.
