Optional Remote Control EEC-0039 V1.1
Remote Control (Optional)
Functions
A. Emergency Stop button (red push button)
Press this button in to kill the truck’s engine. When the Emergency Stop button is
pushed in completely, it will automatically lock and keep the button in a depressed
state. To release the Emergency Stop button, turn the button clockwise and the
button will pop up and allow the transmitter to resume normal functions.
Switch Labels
B. Power, ON/Enable, Horn, Calibrate Button
This push button switch needs to be depressed before operating any of the joysticks.
The horn will sound momentarily when the button is pushed to alert personnel in the
working area that aerial device movement is about to begin. Any time the transmitter
is inactive, the enable will stay active for 15 seconds, and then this switch needs to
be activated again.
C. Start/Stop Switch
This is a momentary switch used to start or stop the truck engine. Holding the switch
in the start position, within 5 seconds of pressing the enable button, activates the
starter. Release the switch as soon as the engine starts. Activate and hold the
switch in the Stop direction to shut the truck off. Once the engine stops completely
stops running, release the switch. If this switch is released while engine is still
turning over, the truck will restart.
