8. Technical Specifications POWER CHARGER PC_ _
Power ratings
Supply Voltage
Start-up current
Output voltage
Output current
Operating mode
Enclosure
Protection class
Ambient operting
temperature
Storage temperature
Ambient Humidity
Dimensions with wall bracket
Weight
UL Approval
Performance Level d
Approval
PC_ _/_ _ _L: 24 V DC ±15%, 100 W
PC_ _/_ _ _S: 90 - 264 V AC, 47 - 63 Hz, 100 W
PC_ _/_ _ _H: 90 - 264 V AC, 47 - 63 Hz, 200 W
The voltage at the input plugs of the 24 V DC supply voltage,
the analog interfaces for charging and discharging and the
field bus interfaces must not exceed 60 V DC.
max. 25 A
Charge: U
min
- U
max
see table page 11
Discharge: 3,5 - 5 kV AC, 50 Hz
Charge: I
min
- I
max
see table page 11
Discharge: max. 6.2 mA (depending on variant)
Current constant resp. Voltage constant
Aluminum coated
IP54 according EN 60529
+5…+50°C (+41…+122°F)
-20…+80°C (-4…+176°F)
max. 80% r.h. non-condensing
106 x 232 x 394 mm (H x W x D)
max. 8 kg (depending on the generator variant)
File No. E227156
depending on the generator variant
see nameplate
Release The requirements for PELV (Protective Extra Low Voltage) or
SELV (Safety Extra Low Voltage) must be fulfilled.
