Functions of the video door entry unit
Warnings for device coding and programming.
The identification phase (coding via numerical identification - ID) for some devices of the Due Fili (Two-Wire)
system is done during the programming phase while for others it is done with jumpers or dip-switches in the
device and that must be set during the phase of installation (see the instruction sheets of the single devices).
IMPORTANT: In order to program the video door entry unit, the system must include the MASTER electronic
panel and the power supply.
The various devices must be programmed after they have been identified and that is after saving the ID; this
programming can be done with electronic panels art. 0200.., with the PC, USB interface 692I/U and “EVCom”
software.
Device programming phases.
For the correct configuration and programming of the system, follow this procedure in sequence:
- Install and connect all the devices to the system.
- In the case of a video door entry system, set the dip-switches for the video termination as shown in the video
termination selection table (page alongside).
- When there are electronic entrance panels with push buttons, do the hardware programming of any push
button modules.
- In systems with multiple electronic entrance panels, set the SLAVE panels (generally using the specific
jumper) and code without connecting the MASTER entrance panel (ID code of the SLAVE panels between
2 and 15).
- Connect and power up the MASTER entrance panel (it is the panel with ID = 1).
- Program any entrance panel parameters. The essential parameters to program are shown in the relevant
instruction manuals.
- Code the audio and video door entry units from the MASTER entrance panel.
- Do any advanced programming of the audio and video door entry units (intercom push-buttons, group calls,
digital relay activation….).
