Elvox 5721 User Manual

13
Art. 732H
CP
TA/TE
SE
B2
B1
EXT+
EXT-
VLED
X
M
PA
CA
M
S+
S-
+12V
-L
SR
F2
F1
M
12
TA/TE
Art. 732H
CP
AL
RL
TA/TE
Art. 170/001
Art. 832/030
SE
B2
B1
EXT+
EXT-
VLED
X
M
PA
CA
M
S+
S-
+12V
-L
SR
F2
F1
M
12
TA/TE
12345 1 15
PRI
LOCK control activation.
This command opens the lock of the door or the gate that provides access to the dwelling.
The LOCK OPENING control is activated by tapping the softkey G of the video door entry unit; this control is
always active in both operating states of MONITOR OFF and MONITOR ON respectively.
With reference to the Due Fili (Two-Wire) panel its terminals to be used are the following:
• “S+/S-“ for locks at 12 V dc with low absorption (200 mA max continuous)
• “+12V/SR” for locks with high absorption (specific external relay 12 V dc and dedicated power supply)
The activation time can be programmed as a panel parameter (see the technical documentation of the panel
used).
Example installation:
Figure 9 - Electric lock 12Vdc 200mA max Figure 10 - Electric lock 15Vac 2A max
AL - Elvox power supply Art. 832/030
TE - External video panel
RL - Relay Art. 0170/001
CP - Lock open button
SE - Electric lock
Functions of the video door entry unit
