47
Con guration of the video door entry unit
Configuring the optional functions of the video door entry unit (advanced pro-
gramming with “EVCom”).
With the advanced programming it is possible to configure some optional functions of the video door entry
unit or (when it is possible) this can be accomplished by pressing the appropriate combinations of buttons.
By advanced programming we mean a configuration of the video door entry unit that is accessible only via
auxiliary programming tools such as a PC and the USB interface 692I/U with "EVCom" software; the following
examples refer to the "EVCom" application.
In the EVCom management application the programmable buttons are indicated with
, , ,
P1....
P6.
Setting flags.
Flags are options that you can turn on/off and they affect the behaviour of the video door entry unit; you can
only access flag configuration through the USB interface 692I/U for PC and the "EVCom" software.
The flags that can be set are shown in the following table:
EVCom Flag Description
F1-8
F1/F2 1-8 Enables FUNCTIONS F1/F2 for panels 1 - 8
Consumer unit Enables control via the consumer unit
F9-16
G3 External only Enables Group 3 only for external calls from panel
G4 Internal only Enables Group 4 only for intercom calls
Do not beep Disables the beep when a button is pressed
No RIPCH IC Disables intercom call repetition
G1 External only Enables Group 1 only for external calls from panel
G2 Internal only Enables Group 2 only for intercom calls
No Internal Ringtone Disables the intercom ringtone
No External Ringtone Disables the ringtone of external calls from the entrance panel
F17-24
Lock End Ends the call when you press the softkey G (LOCK)
Grp. Off S. If on “User Away,” the secondary ones ring in any case
Unlim. I.C. Unlimited duration of intercom conversations
Aut. Resp. The video door entry unit passes on to communication at the end
of the ringtone cycle
F25-29
Landing Group Enables creating a Landing Group with article Elvox 6120
Lock > Master Enables Master lock opening with video door entry unit at rest
Ring. Off Ringtone off
User Away Ringtone off + message on panel (alphanumeric)
No Vid. Ch.
Disables checking for a video signal
Select the drop-down menu F1-8, F9-16, etc. to display the related flags.
