Storage processor enclosure (SPE)
EMC VNX7500 Parts Location Guide 15
Table 6 lists the part number label location, part number, description, and whether it is a
FRU or CRU.
Note: For illustrations and part number descriptions of the SP I/O modules, go to “I/O
modules” on page 23.
Table 6 SPE chassis and SP part numbers (rear view)
Part number label
location
(Figure 11 on
page 14) Part number Description FRU CRU
1 100-562-453 SPE (empty)
2 303-129-101B
1
303-129-100B
2
Management module
3 303-163-100B Four-port 6-Gb/s SAS I/O module
4 100-563-228 I/O module filler panel
5 303-092-102B Four-port 8-Gb/s FC (2/4/8 Gb/s)
303-141-100A
3
Four-port 1-Gb/s iSCSI ports
303-081-103B
4
Two-port 10-Gb/s optical with iSCSI
protocol I/O module
303-142-100A
5
Two-port 10-Gb/s Fibre Channel
over Ethernet (FCoE)
303-164-104D-01
6
Two-port 10-Gb/s RJ-45 Base-T
iSCSI/IP
1. This part number is for a management module that includes a USB port.
2. This part number is for a management module that does not include a USB port.
3. This part is not shown in the example SPE illustration in Figure 11 on page 14. For a closer view, go to
Figure 23 on page 28.
4. This part is not shown in the example SPE illustration in Figure 11 on page 14. For a closer view, go to
Figure 24 on page 29.
5. This part is not shown in the example SPE illustration in Figure 11 on page 14. For a closer view, go to
Figure 26 on page 31.
6. This part is not shown in the example DPE illustration in Figure 11 on page 14. For a closer view, go to
Figure 29 on page 34.
