22 EMC VNX7500 Parts Location Guide
Data Mover enclosure
5 100-562-718 I/O module filler panel includes Do
Not Remove label
Note: This filler panel is only used
when the Data Mover I/O module
slots are empty.

303-141-100A
1
Four-port 1-Gb/s Ethernet I/O
Module (for a closer view, see
Figure 23 on page 28)

303-081-103C-01
2
Two-port 10-Gb/s Ethernet Optical
I/O module (for a closer view, see
Figure 27 on page 32)

303-195-100B
3
Two-port 10-Gb/s Ethernet optical
or Twinax I/O module (for a closer
view, see Figure 30 on page 35)

303-164-104D-01
4
Two-port 10-Gb/s RJ-45 Base-T
iSCSI/IP (for a closer view, see
Figure 29 on page 34)

1. This part is not shown in the example 2U Data Mover enclosure illustration in Figure 18 on page 21. For a
closer view, go to Figure 23 on page 28.
2. This part is not shown in the example 2U Data Mover enclosure illustration in Figure 18 on page 21. For a
closer view, go to Figure 24 on page 29.
3. This part is not shown in the example Data Mover enclosure illustration in Figure 18 on page 21. For a closer
view, go to Figure 30 on page 35.
4. This part is not shown in the example Data Mover enclosure illustration in Figure 18 on page 21. For a closer
view, go to Figure 29 on page 34.
Table 12 Data Mover enclosure part numbers rear view (continued)
Part number label
location
(Figure 18) Part number Description FRU CRU
