DPSI RV Mini Family Operating Instructions Version 1.0
Page 17 of 54
Each matching system has its own microcontroller (there are three in
the DPSI RV Mini 5 Magic, one in the DPSI RV Mini 6 Magic).
Resolution (precision) is more than 3000 steps and the delay of the
servo signals is only 1500 micro-seconds!
6. Error Detection and Indication
6.1. IVM (Intelligent Voltage Monitoring)
An internal microcontroller monitors all voltages using an intelligent
algorithm and indicates different errors (overload, low voltage, voltage
errors, battery malfunctions) acoustically by means of a built-in piezo-
buzzer. Furthermore, errors are visualized by blink codes by a LED in
the switch actuator.
Additionally, the DPSI RV Mini allows for connection of external LED-
Displays (battery monitors) directly at the switch actuator.
In order for the DPSI RV Mini to detect low voltages correctly the
battery type must be programmed once. Simple programming allows
for selection of 6 different battery types.
