DPSI RV Mini Family Operating Instructions Version 1.0
Page 22 of 54
9.2. Hole-Spacing for Mounting
9.3. Mounting the Receiver
The receiver can be directly glued onto the DPSI RV Mini by means of
dual sided adhesive foam rubber (approx. 5-10 mm thick). The
programming marks must remain free for Magic versions.
Separate mounting of the receiver is also possible and even
recommended for 2.4GHz receivers. At high current loads and under
combat conditions, the upper surface of the DPSI RV Mini should
remain uncovered in order to allow for unrestricted heat dissipation.
Hint:
The lower side of the DPSI RV Mini where the heat sink resides, must not be
covered or pasted up with something at all and should have at least a distance of
30mm to the next area (fuselage's bottom or similar)! Good air ventilation
(eventually with air hoods or guided cooling air) is especially reasonable when
operating many servos.
