DPSI RV Mini Family Operating Instructions Version 1.0
Page 46 of 54
* Caution:
Programmable values for end positions of the servos can be higher than the
mechanically resolution of the servo. The servo therefore could be damaged or
function incorrectly (e.g. wheel spinning) if the full range is being used. Therefore
approach limits carefully.
11. Connecting Optional Products
Operating the DPSI RV Mini with Gyros
It is possible without any difficulty to operate the DPSI RV Mini in
connection with a gyro. The gyro and its connected servos can be
supplied by the receiver without problems.
Varios, Smoke-Pumps, Retractable Gears and other Consumers
All other types of consumers can be connected to the DPSI RV Mini
just like a normal servo. Using a DPSI RV Mini also allows for
connecting additional auxiliary functions directly at the receiver if the
available slots (channels) of the DPSI RV Mini are not sufficient. Just
observe maximum current (see also technical data).
Ignitions
Even if it appears appealing to supply the ignition system for gasoline
engines by a DPSI we strongly recommend not doing so! Ignitions
induce considerable disturbances which influence the range of the
remote control if integrated into the receiving set. Always supply the
ignition system with a separate battery!
12. Operating
After powering the DPSI RV Mini on, the red ultra bright LED in the
switch actuator and the LED in the DPSI RV Mini illuminate. This
signals operation. Immediately after power on, the signaling device
(buzzer) indicates the programmed battery type (once, twice, three-,
four-, five-, six- or seven times). Afterwards, the algorithm for error
recognition starts.
