DPSI RV Mini Family Operating Instructions Version 1.0
Page 44 of 54
10.7. Changing the Model
If an already programmed DPSI RV Mini is to be used in another
application (e.g. changing the model) all settings should be generally
deleted (see "Deleting of all Programming"). This holds true if even a
servo with different direction is built in.
10.8. Sequence of Programming
When programming the slave servo, set direction first (if necessary).
Then center position and end-positions follow, while the sequence is
not important.
Hint:
Whenever a change of e.g. then servo center position is reprogrammed, end-
positions should be reprogrammed as well!
10.9. Limitation of Range Settings
The DPSI RV Mini only allows for certain values during programming
of the slave servo. Because the slave servo is to be adapted to the
master servo both servos should have a similar basic setting e.g. a
similar center position.
If the servo center of the master servo already exceeds 100% of the
servo deflection it does not make much sense to offset the slave servo
even further. Therefore only a setting of a servo center for a maximum
of +/-100% is possible.
Setting of the slave servo is generally accomplished by a so called 3-
point curve (i.e. center position, maximum value left / upper, maximum
value right / lower).
"Distance" of maximum value to the center position is 20% minimum
otherwise the value is not programmable.
