DPSI RV Mini Family Operating Instructions Version 1.0
Page 43 of 54
If the desired end position is reached, remove the magnet.
Hint:
Whenever changes of servo deflections are programmed, all values should be
reprogrammed, i.e. center position and end-positions! Sequence of programming
(center, end-positions) is actually unimportant.
Caution:
Programmable values for end positions of the servos can be higher than the
mechanically resolution of the servo. The servo therefore could be damaged or
function incorrectly if the full range is being used. Therefore approach limits
carefully. An additionally connected servo tester (e.g. EMCOTEC Mini Servo
Tester – part number A71050) which indicates the corresponding servo position
digitally can be helpful if in doubt.
10.5. Deletion of all Programming
Total reset of all programmed settings is also
possible. Just position the magnet close to the
red dot after powering the DPSI RV Mini on
and keep it there for about 30 seconds. After
2.5 and additional 5 seconds, the servo makes its short move (just like
when programming center / end values). The stick must not be moved
at all during this time and the magnet must remain at its position close
to the red dot. After 30 seconds have elapsed all settings are deleted.
Hint:
Whenever programming is activated the green LED on the DPSIs top side blinks
for controlling purposes in the DPSI RV Mini Magic at a rate of 0.5Hz (1s on, 1s
off).
10.6 Supplemental Hints for MAGIC-Version
These additional hints are valuable for the ambitious user who likes to
know more about the functions of servo-matching by explaining its
behavior under certain circumstances.
