DPSI RV Mini Family Operating Instructions Version 1.0
Page 40 of 54
10.1. Programming
No external operating unit is necessary for programming the slave-
servos such as a PC or a programming box. Only the delivered magnet
serves to activate the corresponding programming function. Everything
else is done with the transmitter (the remote control system).
During programming settings of the original servo (master) do not
change! Programming always refers to the slave servo. The slave
servo connects to the red encircled output. This is the servo at output
"Out 6/2" for the DPSI RV Mini 6 Magic; for the DPSI RV Mini 5
Magic these are outputs "Out 1/2“, "Out 3/2“ and "Out 5/2“.
Hint:
Setting and programming of the slave servo is only possible within the first 10
seconds after powering the DPSI on. Afterwards programming is inhibited for
safety reasons!
Hint:
Prior to EACH programming the corresponding transmitter stick (or switch
actuator) must be positioned in the center!
Hint:
If both servos, MSTR and SLAVE share one rudder at least one link must be
released in order to avoid mechanically blocking of the servos.
Hint:
Whenever the servo center is changed, end-limits should be reprogrammed as
well!
Hint:
Implemented basic settings correspond to servo values of Graupner/JR sets.
Center position is 1.50ms; end-positions are set to 100% each. Of course, all
remote control sets can be utilized.
