DPSI RV Mini Family Operating Instructions Version 1.0
Page 6 of 54
3. DPSI RV Mini at a glance
The DPSI RV Mini – family consists of four different dual current
supply systems with servo current distribution for models of medium
size which fit all applications:
DPSI Version Receiver-
channels
Servo-
connections
Specifics
DPSI RV Mini 5 5 8 3 built in V-cable
DPSI RV Mini 6 6 7 1 built in V-cable
DPSI RV Mini 5
Magic
5 8 3 built in V-cable with
servo-matching
DPSI RV Mini 6
Magic
6 7 1 built in V-cable with
servo-matching
The DPSI RV Mini 5 corresponds to pilots of the 2m to 2.7m air
acrobatic class who need up to 10 servos and where up to 2 servos
actuate one rudder. Therefore, only heavy loaded rudders are supplied
by the DPSI (aileron, elevator and yaw rudder). Servos for additional
functions (e.g. engine, retractable landing gear, etc.) are connected
directly to the receiver.
