Emerson Daniel 3415

Flow Rates (MMSCFD) Based upon 100 ft/s
700 40.3 91.5 158.5 29.8 354.5 559.7 880.4 1 273 2 056 2 961
800 46.6 105.8 183.2 288.9 410.0 647.2 1 018 1 472 2 378 3 424
900 53.1 120.5 208.7 328.9 466.8 737.0 1 159 1 677 2 708 3 899
1000 59.7 135.5 234.6 369.9 252.0 828.9 1 304 1 886 3 045 4 385
1100 66.5 150.9 261.2 411.9 584.5 922.8 1 451 2 099 3 390 4 882
1200 73.4 166.5 288.4 454.6 645.2 1 019 1 602 2 317 3 742 5 389
1300 80.4 182.4 315.9 498.1 706.9 1 116 1 755 2 539 4 100 5 904
1400 87.5 198.6 343.8 542.1 769.3 1 215 1 910 2 763 4 462 6 425
1500 94.7 214.9 372.1 586.6 832.5 1 314 2 067 2 990 4 828 6 953
1600 101.9 231.3 400.4 631.3 896.0 1 415 2 225 3 218 5 196 7 483
1700 109.1 247.7 428.9 676.2 959.7 1 515 2 383 3 447 5 566 8 015
1800 116.4 264.0 457.2 720.9 1 023 1 615 2 540 3 674 5 933 8 544
1900 126.5 280.3 485.4 765.3 1 086 1 715 2 697 3 901 6 299 9 071
2000 130.6 296.4 513.3 809.2 1 148 1 813 2 852 4 142 6 660 9 591
Flow Rates (MMSCMD) Based upon 30 M/s
kPag 4 6 8 10 12 16 20 24 30 36
1000 0.232 0.528 0.915 1.442 2.046 3.231 5.082 7.350 11.869 17.091
1500 0.341 0.776 1.344 2.119 3.007 4.748 7.468 10.801 17.441 25.116
2000 0.453 1.029 1.783 2.810 3.989 6.297 9.904 14.325 23.133 33.311
2500 0.566 1.288 2.231 3.516 4.991 7.879 12.393 17.924 28.946 41.682
3000 0.682 1.552 2.688 4.237 6.014 9.495 14.935 21.600 34.882 50.230
3500 0.801 1.821 3.155 4.973 7.059 11.145 17.530 25.354 40.943 58.958
4000 0.922 2.097 3.632 5.725 8.126 12.830 20.179 29.186 47.131 67.869
4500 1.045 2.378 4.119 6.492 9.215 14.549 22.883 33.097 53.447 76.963
5000 1.171 2.664 4.615 7.239 10.326 16.302 25.641
8.0911
37.086 59.889 86.240
5500 1.300 2.957 5.121 7.789 11.459 18.091 28.454 41.154 66.458 95.699
6000 1.431 3.254 5.637 8.347 12.612 19.912 31.319 45.298 73.150 105.33
6
6500 1.564 3.557 6.162 9.713 13.787 21.767 34.236 49.517 79.964 115.14
8
7000 1.700 3.866 6.696 10.555 14.982 23.653 37.203 53.808 86.893 125.12
6
7500 1.837 4.179 7.239 11.410 16.196 25.570 40.218 58.168 93.934 135.26
5
Flow Rate summary charts
Operations manual 139
