Emerson Daniel 3415

Configure Operational parameters (continued)Table 5-5:
Calibration selection Description
AGA8 calculations () Configure the properties necessary for the AGA8 calculations. Selec-
tions include:
• Gross Method 1
• Gross Method 2
• Detail
• Externally
Continuous flow analysis () Configure the Continuous Flow Analysis features. Selections include:
• Flow limits
• SOS comparison
• Liquid detection
• Abnormal profile
Local Display () Configure the local display settings. Selections include:
• Display units
• Display Items
• Scroll Delay
5.2 Calibrate analog inputs and outputs
NOTICE
The WRITE PROT. switch on the CPU Module must be disabled or the calibration values will not
be updated for a meter.
An analog input can be calibrated regardless of the corresponding input type, pressure of
temperature. However, if the corresponding input type is selected as Live, then the input being
calibrated is considered to be invalid and the in-use value depends upon the
FlowPOrTSrcUponAlarm selection (see above). In this case, the appropriate data point
(FlowPressureWhileCal, FlowTemperatureWhileCal) is set to the in-use value so that it can be
logged in the optional log.
The offset and gain can be reset to the default values (0 and 1, respectively) by clicking the
Reset Defaults button.
NOTICE
Clicking the Reset Defaults button writes the offset and gain immediately - the previous values
cannot be restored.
Click the Edit Scaling button to modify the input scaling.
NOTICE
Changes made to an analog input's offset, gain, and scaling values are written to the log.
From Daniel MeterLink, select Calibrate to make changes using the Analog Inputs Wizard.
Configurations
48 3410 Series Gas Ultrasonic Flow meters
