5 Configurations
Topics covered in this chapter:
•
Calibrate and configure the meter
•
Calibrate analog inputs and outputs
•
Calibrate meter factors
•
Configure frequency outputs
•
Configure digital input/outputs
•
Outputs test mode
•
Configure HART outputs
•
Configure Meter corrections
•
Configure Temperature and Pressure
•
Configure Gas Chromatograph parameters
5.1 Calibrate and configure the meter
Use Daniel MeterLink
™
to calibrate and configure the meter parameters: Analog (current),
Meter Factors, Flow Calibration, Frequency/Digital Output Sources, Frequency and Digital
inputs and outputs, HART output, Meter corrections (for transmitter head 2 of Model 3415
and 3416), Temperature and Pressure, AGA8 calculations, and Local Display parameters.
5.1.1
Calibration methods
The Daniel 3410 Series Gas Ultrasonic Flow meter uses two calibration steps: "dry"
calibration and "wet" calibration.
In this methodology, the "dry-calibration" values are set by Daniel at the factory and are not
expected to be modified; the "wet-calibration" values are expected to be set as the result of
a user flow calibration (if desired). These two calibration methods are explained in further
detail below.
Important
The WRITE PROT. switch on the CPU Module must be disabled (OFF) before writing calibration
factors to the meter.
After the meter is configured, enable the WRITE PROT. switch (ON) to write-protect the
configuration.
Collect a Maintenance Log and configuration file the meter's "As left" configuration settings.
