Emerson Daniel 3415

Gating configuration parameter Edge gated, active highFigure 5-6:
• Edge gated, active low
Gating configuration parameter Edge gated, active lowFigure 5-7:
•
State gated, active high
Gating configuration parameter State gated, active highFigure 5-8:
• State gated, active low
Configurations
52 3410 Series Gas Ultrasonic Flow meters
