Frequency/Digital output Source configuration
Frequency /Digital Output 1
Frequency /Digital Output 2
Frequency /Digital Output 3
Frequency /Digital Output4
Frequency /Digital Output 5
Frequency /Digital Output 6
• Frequency output 1A
• Frequency output 1B
• Digital output 1A
• Digital output 1B
• Frequency output 2A
• Frequency output 2B
• Digital output 2A
• Digital output 2B
Output for FODO1 and Digital Input 1 (Group 1 on the CPU Module) share a common
ground and have 50V isolation. FODO2 and FODO3 (Group 2 on the CPU Module) share a
common ground and have 50V isolation. This allows an output to be connected to a
different flow computer. The outputs are opto-isolated from the CPU Module and have a
withstand voltage of at least 500V rms dielectric.
Configurations
Operations manual 55
