For example, if the C
6
PlusGC mole percentage is 1% and its component ID is 110, then 60%
of the C6+ mole percentage (0.60x1%=0.60%) is added to NHexaneInUse, 30%
(0.30x1%=0.30%) is added to NHeptaneInUse, and 10% (0.10x1%=0.10%) is added to
NOctaneInUse.
The GC-reported NeoPentane component (NeoPentaneGC) quantity is added to the
IsoPentane component (IsoPentaneInUse).
The validity of the "In-Use" gas property data is readable via the
AreGasPropertiesInvalidInUse data point where TRUE(1) indicates invalid data and
FALSE(0) indicates valid data. The validity of the "In-Use" gas property data is a function of
the validity of the selected source data. If the source data is selected as Fixed, then the "In-
Use" gas property data is valid (since the fixed data is assumed to be valid). If the source
data is selected as Live - GC, then the "In-Use" gas property data is valid only if the GC-read
gas property data is valid.
Optional gas chromatograph interface
The Daniel 3410 Series Gas Ultrasonic Flow Meter can optionally interface with any Daniel
gas chromatograph (GC) that supports the SIM 2251 mode to read gas property data (such
as for AGA8, AGA10, energy rate, mass rate, and/or profile correction calculations).
The following table lists the Gas Chromatograph SIM registers polled by the meter. Also
refer to Daniel Engineering Specification Part Number ES-17128-005 Rev. B.
Gas chromatograph Sim 2251 RegistersTable 5-12:
Sim 2251 Register Description
3034 Stream identifier
3041 Cyc le time start - month(1-12)
3042 Cyc le time start - day(1-31)
3043 Cyc le time start - last two year digits
3044 Cyc le time start - hour(0-23)
3045 yc le time start - minutes(0-59)
3046 GC alarm bitmap 1
3047 GC alarm bitmap 2
3001 - 3016 Component codes
7001 - 7016 Mole fractions for corresponding component codes
7033 BTU (dry)
7034 BTU (sat)
7035 Specific gravity)
7038 Total unnormalized mole percent
7054 BTU (actual)
