6.3.1 Writing the converted configuration file to the meter
Procedure
1. With communication to the meter established, use the Tools|Edit/Compare
Configuration menu path to access the Edit/Compare Configuration dialog.
2. Click Open and the Open Configuration File dialog displays.
Figure 6-4: Edit/Compare configuration dialog
a) Select the final 3400 configuration file created in Step 2 of Section 3 of this
document (i.e., “Meter Name, MKIII Final Config, 3-4-2005 10-15-02
AM.cfg”).
b) Click Open. The file opens and you returned to the Edit/Compare
Configuration dialog.
Figure 6-5: Open configuration file dialog
Upgrade kit instructions Configure the 3410 Series Electronics
P/N 3-9000-784 July 2019
3410 Series Electronics Upgrade kit instructions 53
