Flowmeter Startup
Required Configuration Optional ConfigurationUsing the TransmitterFlowmeter Startup
Figure 5-3 ProLink II – Loop test procedure
Figure 5-4 Communicator – Loop test procedure
Fix Milliamp 1/2 Fix Discrete Output Read Discrete Input
Enter mA value ON or OFF
Read output at
receiving device
Verify state at
receiving device
Toggle remote input
device
Verify state
at transmitter
Correct? Correct? Correct?
Check output wiring
Troubleshoot receiving device
Loop test successful
Check input wiring
Troubleshoot input device
Yes No Yes No
Fix Freq Out
Read output at
receiving device
Correct?
Enter Hz value
Fix mA Fix Frequency
Unfix
ProLink Menu >
Test
1 Fix Analog Out 1/2 3 Fix Discrete Out 1
ON or OFF
Read output at
receiving device
Verify state at
receiving device
Correct? Correct?
Loop test successful
END to unfix
Check output wiring
Troubleshoot receiving device
Yes No
2 Fix Frequency Out
Read output at
receiving device
Correct?
4 mA
20 mA
Other
10 kHz
Other
On-Line Menu >
3 Diag/Service >
2 Loop test
