INSTALLATION AND MAINTENANCE TRAINING MANUAL
5.1 Tools
For stripping techniques, Emtelle advise the use of the following tools. Other tools may not be as effective or cost effective. It is also recommended that a
measuring tape and marker pens (black and white) be included, and while these are typically found in most installers’ toolboxes they can be purchased
from Emtelle. Tools may be purchased separately or they can be supplied complete with the toolbox (as shown). Not all the listed tools are illustrated
9088 toolbox
9344 diagonal cutters
9346 heavy duty cutter
7041 flexi-saw
9343 sheath stripper
7001 stripper (long’l)
7236 collet lock tool
7710 sheath stripper
7949 rounding tool
7014 primary cutter
7794 1DB stripper
7071 rotary cutter
7299 m/d rotary cutter
5 Tube assembly preparation
1. Code 9088 Toolbox 11. Code 7299 Primary Tube Rotational Cutter
2. Code 9343 Sheath Stripper 4.5-26mm 12. Code 9346 42 mm Heavy Duty Cutter
3. Code 7710 Sheath Stripper 19-40mm 13. Code 9345 Screwdriver Pack
4. Code 7794 Stripper 1DB 14. Code 7298 Junior Hack Saw
5. Code 9344 Diagonal Cutters 15. Code 7041 Flexi Saw
6. Code 7301 Pliers 16. Code 7300 Brush Sash Tool
7. Code 7069 Stanley Knife 17. Code 7949 Microduct Rounding Tool
8. Code 7001 Longitudinal Cable Stripper 18. Code 7014 Primary Tube Cutter
9. Code 7071 Rotational Sheath Stripper 19. Code 7236 Collet Locking Tool
10. Code 7039 Scissors
“This document is intended as a guide only. Whilst the information it contains is believed to be correct, Emtelle can take no responsibility for actions taken based on the information contained in this document. Emtelle reserves the
right to make changes to this document without notice. All sales of product are subject to Emtelle’s terms and conditions of sale only, which can be found on Emtelle’s website.”
