INSTALLATION AND MAINTENANCE TRAINING MANUAL
Accessory Product Nnumber Typical Maximum Capacity
Intercept Assembly Branch off Assemblies
In Out Tube OD
(mm)
3mm 5mm 10mm 12mm
Tube Distribution
Closure (TDC)
7514 1x24 DB 1x24DB 3,5 4 ports
6x1 DB each
or 1x24 DB
(or less) each
4 ports
6x1 DB each
or 1x24 DB
(or less) each
Tube Distribution
Manifold (TDM)
7849 1x24 DB or
1x19 DB
3,5 contact
Emtelle
24x1 DB or
14x1 DB
plus 1x4 DB
plus 1x7 DB
contact
Emtelle
Y Branch
(3mm)
7954 1x24 DB 1x24DB 3 6x1 DB
Y Branch
(5mm)
9169 1x24 DB 1x24DB 5 4x1 DB
Y Branch
(Indoor)
9018 1x24 LFH 1x24 LFH 5 6x1 LFH
H Branch 9190
1x24 DB (5)
1x7 DB (10)
1x24 DB (5)
1x7 DB (10)
3,5
10
6x1 DB 6x1 DB 1x1 DB
Customer Connection
Point (CCP)
9358 1 way N/A 3, 4, 5, 8
3A 7247 2x24 DB
(3,5mm)
(4) 3, 5, 10, 12 4 ports out,
40mm
maximum
24 DB each
4 ports out,
40mm
maximum
24 DB each
4 ports out,
40mm
maximum
7 DB each
4 ports out,
40mm
maximum
5 DB each
Customer Lead In
Point (CLIP)
7500 1x1 DB 3,5 1x primary 1x primary
Direct Bury Joint Kit
(DBJ)
7719 1x2 DB 5 2x1 DB
Direct Bury Joint Kit
(DBJ)
7720 1x4 DB 5 4x1 DB
H Closure tba 2 ports
50mm each
2 ports
50mm each
Indoor Tube Flexibility
Point 3 Port (ITFP)
7258 1x19 DB 1x19 LFH 5 3 ports
giving 1
branch off
assembly
maximum
19 DB
Indoor Tube Flexibility
Point 4 Port (ITFP)
7217 1x19 DB 1x19 LFH 5 4 ports
giving 2
branch off
assembly
maximum
19 DB each
Aerial Closure 9257 Aerial Fig.8 Aerial Fig.8 3,5, 15*
* 1-way
5 ports x
1 drop
5 ports x
1 drop
6 Closures And Their Selection
