Commissioning with an operating menu (onsite display/FieldCare) Cerabar M, Deltabar M, Deltapilot M
132 Endress+Hauser
Expert → Application → Totalizer 1 (Deltabar M)
With the "Flow in %" flow type setting, the totalizer is not available and is not displayed at
this position.
Parameter name Description
Eng. unit totalizer 1
(058) (059) (060) (061)
Options
Select unit for totalizer 1.
Options
Depending on the setting in the "Flow type (044)" parameter, this parameter offers
a list of volume, norm volume, standard volume and mass units. When a new
volume or mass unit is selected, totalizer-specific parameters are converted and
displayed with the new unit within a unit group. When the flow mode is change,
the totalizer value is not converted.
The Direct Access Code depends on the selected "Flow type (044)":
– (058): Flow. meas. type "Mass"
– (059): Flow. meas. type "Volume norm. cond."
– (060): Flow. meas. type "Volume std. cond."
– (061): Flow. meas. type "Volume process cond."
Factory setting:
m
3
Totalizer 1 mode (175)
Options
Define the behavior of the totalizer.
Options:
• Balanced: Integration of all measured flows (positive and negative)
• Pos. flow only: only positive flows are integrated.
• Neg. flow only: only negative flows are integrated.
• Hold: The totalizer is stopped and keeps its current value.
Factory setting:
Pos. flow only
Totalizer 1 failsafe (176) Define the behavior of the totalizer in the case of an error.
Options:
• Actual value (It is integrated with the current flow value on.)
• Hold: The totalizer is stopped and keeps its current value.
Factory setting:
Actual value
Reset Totalizer 1 (062)
Options
You reset totalizer 1 to zero with this parameter.
Options:
• Abort (do not reset)
• Reset
Factory setting:
Abort
Totalizer 1 (063)
Display
Displays the total value of totalizer 1. You can reset the value with the "Reset
Totalizer 1 (062)" parameter. The "Totalizer 1 overflow (064)" parameter displays
the overflow.
Example: The value 123456789 m
3
is indicated as follows:
– Totalizer 1: 3456789 m
3
– Totalizer 1 overflow: 12 E7 m
3
Totalizer 1 overflow
(064)
Display
Displays the overflow value of totalizer 1.
See also "Totalizer 1 (063)".
