Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 165
Block configuration when device is delivered
The block model shown below illustrates the block configuration when the device is
delivered.
A0030418
Fig. 51: Block configuration when device is delivered
Cerabar M/Deltapilot M
The Pressure Transducer Block returns the primary value (measured value) and the
secondary value (sensor temperature). The Primary Value and Secondary Value are each
transmitted to an Analog Input Block via the Channel/CHANNEL parameter ( ä 211,
Channel/CHANNEL parameter description). The Discrete Output, Discrete Input, PID,
Arithmetic, Input Selector and Integrator are not connected in the as-delivered state. (IT, DI).
Deltabar M
The Pressure Transducer Block returns the Primary Value (measured value) and the
Secondary Value (max. pressure). In the DP_FLOW Transducer Block, the flow is totalized in
the "Flow" measuring mode and output by means of the Totalizer 1/TOTALIZER_1 and
Totalizer 2/TOTALIZER_2 record parameter. The Primary Value, Secondary Value and
Totalizer 1 and 2 values are each transmitted to an Analog Input Block via the Channel/
CHANNEL parameter ( ä 211, Channel/CHANNEL parameter description). The Discrete
Output, PID, Arithmetic and Input Selector are not connected in the as-delivered state. (IT,
DI)
CAUTION
!
Note Dependencies when setting parameters!
‣ Please note that links between the blocks are deleted and the FF parameters are reset to
the default values following a reset by means of the Restart/RESTART parameter in the
Resource Block, "Default" option.
Pressure
Transducer Block
Analog Input Block 1
CHANNEL = 1
L_TYPE = Direct
Analog Input Block 2
Analog Input Block 2
CHANNEL =2
CHANNEL = 3
L_TYPE = Direct
L_TYPE = Direct
Display
Transducer Block
Diagnostic
Transducer Block
Primary value
Resource Block
Integrator
Block
Discrete Input
Block
PID Block
Input Selector
Block
Signal
Characterizer
Block
Discrete
Output Block
Arithmetic
DP flow Block
Block
Measured variable
Sensor
Signal evaluation
Display
with scaling
Sensor temperature
Deltabar M: measured pressure
