Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 169
Nonvolatile Cycle Time/
NV_CYCLE_T
Display
Index: 23
Data type: unsigned32
Access: read only
Displays the time interval for which the dynamic device parameters are stored in the
nonvolatile memory.
5760000 1/32 ms  180s
Free Space/
FREE_SPACE
Display
Index: 24
Data type: float
Access: read only
Displays the system memory (in percent) available for the execution of further
function blocks. This parameter is not supported by Deltabar M, Cerabar M and
Deltapilot M.
Free Time/FREE_TIME
Display
Index: 25
Data type: float
Access: read only
Displays the free system time (in percent) available for the execution of further
function blocks. This parameter is not supported by Deltabar M, Cerabar M and
Deltapilot M.
Shed Remote Cascade/
SHED_RCAS
Entry
Index: 26
Data type: unsigned32
Access: wr for Auto,
OOS
Enter the monitoring time for checking the connection between the fieldbus host
system and the PID function block in the RCAS block mode. On expiry of this
monitoring time the PID function block switches from the RCAS block mode to the
block mode selected via the Shed Options/SHED_OPT parameter.
Factory setting:
640000
1
/
32
ms
Shed Remote Out/
SHED_ROUT
Entry
Index: 27
Data type: unsigned32
Access: wr for Auto,
OOS
Enter the monitoring time for checking the connection between the fieldbus host
system and the PID function block in the ROUT block mode. On expiry of this
monitoring time the PID function block switches from the ROUT block mode to the
block mode selected via the Shed Options/SHED_OPT parameter.
Factory setting:
640000
1
/
32
ms
Fault State/
FAULT_STATE
Display
Index: 28
Data type: unsigned8
Access: read only
Current status display of the fault state of the Discrete Output function block.
Possibilities:
• Uninitialized
• Clear (fault state not active)
• Active (fault state active)
Set Fault State/
SET_FSTATE
Options
Index: 29
Data type: unsigned8
Access: wr for Auto,
OOS
Activate the fault state of the Discrete Output function block manually.  See also this
table, Clear Fault State/CLR_FSTATE parameter description.
Possibilities:
• Uninitialized
•Off
• Set (the fault state is enabled)
Clear Fault State/
CLR_FSTATE
Options
Index: 30
Data type: unsigned8
Access: wr for Auto,
OOS
Deactivate the fault state of the Discrete Output function block manually.  See also
this table, Set Fault State/SET_FSTATE parameter description.
Possibilities:
• Uninitialized
•Off
• Clear (fault state is disabled)
Resource Block - standard parameters
Parameter Description
