Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
180 Endress+Hauser
Sensor Type/
SENSOR_TYPE
Options
Index: 20
Data type: unsigned16
Access: OOS
Depending on the sensor type.
Factory setting:
"Capacitance", "Piezo resistive" or "MANUFACTOR SPEC".
• Flow sensor unknown
•Coriolis
• Electromagnetic
•mV
•Ohms
•Delta Ohms
• Nuclear magnetic resonance
• Positive displacement
• Refraction
•Taggin
• Ultrasonic (Doppler)
• Ultrasonic (time of travel)
•Target
• Variable Area
• Level sensor unknown
• Radar
• Capacitance
•Nuclear
• Ultrasonic
•Float gauge
• Pressure sensor unknown
• Resonant wire
•Vibrating beam
•Strain gauge
• Piezo resistive
• Silicon resonant
• Temperature sensor unknown
• PT100_A_385 (IEC 751)
• PT100_A_392 (JIS 1604)
• PT200_A_385 (IEC 751)
• PT500_A_385 (IEC 751)
• NI120, Edison #7
• CU10, Edison #15
• T/C Type B (IEC 584-1 und NIST 175)
• T/C Type C (NIST 175)
• T/C Type E (IEC 584-1 und NIST 175)
• T/C Type J (IEC 584-1 und NIST 175)
• T/C Type K (IEC 584-1 und NIST 175)
• T/C Type N (IEC 584-1 und NIST 175)
• T/C Type R (IEC 584-1 und NIST 175)
• T/C Type S (IEC 584-1 und NIST 175)
• T/C Type T (IEC 584-1 und NIST 175)
• T/C Type DIN L (DIN 43710)
• T/C Type DIN U (DIN 43710)
• MANUFACTOR SPEC.
•Non-Std Snsr
Sensor range/
SENSOR_RANGE
Display
Index: 21
Data type: DS-68
Access: read only
The Sensor range/SENSOR_RANGE parameter is a structured parameter consisting of
four elements.
EU_100
• Displays the upper-range limit of the sensor.
EU_0
• Displays the lower-range limit of the sensor.
UNITS_INDEX
• Displays the unit selected.
DECIMAL
• Displays the number of decimal places.
Pressure Transducer Block (Profile parameters)
Parameter Description
