Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 179
Hi Trim Sensor/
CAL_POINT_HI
Display
Index: 16
Data type: float
Access: read only
Enter the upper point of the sensor characteristic curve in the event of sensor
recalibration.
By means of this parameter, you can assign a new target pressure value to a reference
pressure present at the device. The pressure value present and the target pressure
value specified for this parameter correspond to the upper point in the sensor
characteristic curve. Position adjustment has to be performed again for the device
following sensor recalibration.
• The sensor recalibration can be reset via the Reset/RESET_INPUT_VALUE
( ä 207) parameter with the "2509" code.
• Hi trim measured/PRESSURE_1_UPPER_CAL_MEASURED ( ä 184) displays the
pressure that was present at the device during calibration and was used for the
calibration of the upper point of the sensor characteristic curve.
• For calibrating the lower point of the sensor characteristic curve, see the Lo trim
sensor/CAL_POINT_LO parameter description.
Factory setting: High sensor limit (Sensor range/SENSOR_RANGE, EU_100
element)
Lo trim sensor/
CAL_POINT_LO
Display
Index: 17
Data type: float
Access: read only
Enter the lower point of the sensor characteristic curve in the event of sensor
recalibration.
By means of this parameter, you can assign a new target pressure value to a reference
pressure present at the device. The pressure value present and the target pressure
value specified for this parameter correspond to the lower point in the sensor
characteristic curve. Position adjustment has to be performed again for the device
following sensor recalibration.
• The sensor recalibration can be reset via the Reset/RESET_INPUT_VALUE
( ä 178) parameter with the "2509" code.
• The Lo trim measured/PRESSURE_1_LOWER_CAL_MEASURED ( ä 184)
parameter displays the pressure that was present at the device during calibration
and was used for the calibration of the lower point of the sensor characteristic
curve.
• For calibrating the upper point of the sensor characteristic curve, see Hi Trim
Sensor/CAL_POINT_HI parameter description.
Factory setting: Low sensor limit (Sensor range/SENSOR_RANGE, Element EU_0)
Cal min span/
CAL_MIN_
SPAN
Display
Index: 18
Data type: float
Access: read only
Displays the smallest possible span.
Press. eng. unit/
CAL_UNIT
Entry
Index: 19
Data type: unsigned16
Access: OOS
Select the pressure unit.
If a new pressure unit is selected, all pressure-specific parameters are converted and
displayed with the new unit.
Options
• mbar, bar
•mmH
2
O, mH
2
O, inH
2
O, ftH
2
O
• Pa, kPa, MPa
•psi
•mmHg, inHg
•kgf/cm
2
Factory setting:
mbar or bar depending on the sensor nominal measuring range, or as per order
specifications
Pressure Transducer Block (Profile parameters)
Parameter Description
