Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 183
DIP switch/
SWITCH_STATUS_LIST
Display
Index: 34
Data type: unsigned8
Access: read only
Displays the DIP switches activated on the electronic insert.
• P1/P2 switch (Deltabar, inputs inversion enabled)
•Lin/sq. switch (Deltabar, flow has been enabled)
• Simulation switch (AI simulation enabled)
• Damping switch (damping enabled)
• HW lock. switch (HW locking enabled)
Scale In/SCALE_IN
Entry
Index: 35
Data type: DS-65
Access: OOS
The Scale In/SCALE_IN-parameter is a structured parameter consisting of four
elements.
EU_100
• "Pressure" measuring mode; "Level in pressure" measuring mode; "Level in
height" measuring mode; enter the upper limit for the pressure value of the
Transducer Block.
• "Flow" measuring mode: Enter the maximum pressure of the primary device.
See layout sheet of primary element. This value is assigned to the
maximum flow value (See the following Scale Out/SCALE_OUT parameter,
EU_100 element).
• Factory setting: Upper range limit of the sensor
EU_0
• "Pressure" measuring mode; "Level in pressure" measuring mode; "Level in
height" measuring mode; "Flow" measuring mode: Enter the lower limit for the
pressure value of the Transducer Block.
• Factory setting: 0
UNITS_INDEX
• Select the unit for input scaling.
DECIMAL
• Displays the number of decimal places.
Scale Out/SCALE_OUT
Entry
Index: 36
Data type: DS-68
Access: OOS
The Scale Out/SCALE_OUT-parameter is a structured parameter consisting of
four elements.
EU_100
• "Pressure" measuring mode; "Level in pressure" measuring mode; "Level in
height" measuring mode; enter the upper limit for the output value of the
Transducer Block.
Factory setting: 100
• "Flow" measuring mode: Enter the maximum flow of the primary device.
See also layout sheet of primary element. The maximum flow is assigned to
the maximum pressure which you enter via the Scale In/SCALE_IN
parameter, EU_100 element.
Factory setting: 1.0
EU_0
• "Pressure" measuring mode; "Level in pressure" measuring mode; "Level in
height" measuring mode; enter the lower limit for the output value of the
Transducer Block.
• Factory setting: 0
UNITS_INDEX
• Select the unit for output scaling.
DECIMAL
• Displays the number of decimal places.
Make sure that the unit selected by means of the Scale Out/SCALE_OUT
parameter, "Units Index" element suits the measured variable.
See also the Primary Value Type/PRIMARY_VALUE_TYPE ( ä 178)
parameter descriptions.
Pressure Transducer Block (Endress+Hauser parameters)
Parameter Description
