Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
182 Endress+Hauser
Secondary Value/
SECONDARY_VALUE
Display
Index: 29
Data type: DS-65
Access: read only
The Secondary Value/SECONDARY_VALUE parameter is a structured parameter
consisting of two elements.
VALUE
• Displays the second process value, here the sensor temperature.
STATUS
• Displays the status of the second process value.
You can transmit the value and status of the Secondary Value/SECONDARY_VALUE
parameter via the Channel/CHANNEL parameter ( ä 211) in the Analog Input
Block. The Channel/CHANNEL parameter must be set to "2" (Cerabar/Deltapilot) or "4"
(Deltabar) for this purpose.
Secondary Value Unit/
SECONDARY_VALUE_
UNIT
Options
Index: 30
Data type: unsigned16
Access: wr for Auto,
OOS
Select the unit for the second process value.
 See also the Secondary Value/SECONDARY_VALUE parameter description.
Pressure Transducer Block (Endress+Hauser parameters)
Parameter Description
Device dialog/
DEVICE_DIALOG
Display
Index: 31
Data type: unsigned8
Access: read only
If configuration is unsuitable, this parameter displays a message indicating that
a configuration error is present. The message can indicate which parameter was
incorrectly configured.
Operator code/S_W_LOCK
Entry
Index: 32
Data type: unsigned16
Access: wr for Auto, OOS
Use this function to enter a code to lock or unlock operation.
Options:
•To lock: Enter a number  the release code.
• To unlock: Enter the release code.
The release code is "0" in the order configuration. Another release code can be
defined in the Code definition/USER_S_W_UNLOCK parameter. If the user has
forgotten the release code, it can be made visible again by entering the number
sequence "5864".
Factory setting:
0
Lockstate/STATUS_LOCKING
Display
Index: 33
Data type: unsigned8
Access: read only
Displays the current locking status of the device or conditions that can lock the
device (hardware locking, software locking).
Pressure Transducer Block (Profile parameters)
Parameter Description
