Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
196 Endress+Hauser
DIP switch/
SWITCH_STATUS_LIST
Display
Index: 14
Data type: unsigned8
Access: read only
Displays the DIP switches activated on the electronic insert.
• P1/P2 switch (Deltabar, inputs inversion enabled)
•Lin/sq. switch (Deltabar, flow has been enabled)
• Simulation switch (AI simulation enabled)
• Damping switch (damping enabled)
• HW lock. switch (HW locking enabled)
Flow meas. type/FLOW_TYPE
Options
Index: 15
Data type: unsigned8
Access: OOS
Select the flow type.
Prerequisite:
• Deltabar M differential pressure transmitter
Options
• Volume process cond. (volume under operating conditions)
• Volume norm. cond. (norm volume under norm conditions in Europe:
1013.25 mbar and 273.15 K (0 °C))
• Volume std. cond. (standard volume under standard conditions in USA:
1013.25 mbar (14.7 psi) and 288.15 K (15 °C/59 °F))
• Mass p. cond. (mass under operating conditions)
•Flow in %
Factory setting:
Volume operat. cond.
Flow/
FLOW_AFTER_SUPPRESSION
Display
Index: 16
Data type: float
Access: read only
Displays the current flow. Depending on the flow mode selected
(→ Flow meas. type/FLOW_TYPE), a volume flow, mass flow, standard volume
flow or corrected volume flow is displayed.
DP_FLOW Transducer Block
Parameter Description
