Cerabar PMP21 IO-Link Accessories
Endress+Hauser 61
15 Accessories
15.1 Weld-in adapter
Various weld-in adapters are available for installation in vessels or pipes.
Description Option
1)
Order number
Weld-in adapter G½, 316L QA 52002643
Weld-in adapter G½, 316L 3.1 EN10204-3.1 material, inspection
certificate
QB 52010172
Weld-in tool adapter G½, brass QC 52005082
Welding neck G1/2, 316L, for G1/2 A DIN 3852 QM 71389241
Welding neck G1/2, 316L, 3.1, for G1/2 A DIN 3852, EN10204-3.1
material inspection certificate
QN 71389243
1) Product Configurator, order code for "Enclosed accessories"
If installed horizontally and weld-in adapters with a leakage hole are used, ensure that the
leakage hole is pointing down. This allows leaks to be detected as quickly as possible.
15.2 M12 plug-in jacks
M12 plug (self-configurable connection to M12 plug)
• Degree of protection: IP67
• Material:
• Union nut: Cu Sn/Ni
• Body: PBT
• Seal: NBR
• Option
3)
: R1
• Order number: 52006263
M12 plug, angled with 5 m (16 ft) cable
• Degree of protection: IP67
• Material:
• Union nut: GD Zn/Ni
• Body: PUR
• Cable: PVC
• Cable colors:
• 1 = BN = brown
• 2 = WT = white
• 3 = BU = blue
• 4 = BK = black
• Option
4)
: RZ
• Order number: 52010285
3) Product Configurator: order code "620"
4) Product Configurator: order code "620"
