Cerabar M, Deltabar M, Deltapilot M / 4...20 mA HART Identification
Endress+Hauser 7
P01-xxxxxxxx-18-xx-xx-xx-000
Fig. 2: Additional nameplate for devices suitable for oxygen applications
1 Maximum pressure for oxygen applications
2 Maximum temperature for oxygen applications
3 Layout identification of the nameplate
Stainless steel housing, hygienic
P01-xMx5xxxx-18-xx-xx-xx-001
Fig. 3: Nameplate for Cerabar M and Deltapilot M
1 Device name
2 Ordercode (complete)
3 Orderident (for re-orders)
4 Serial number (for identification)
5 Nominal measuring range
6 MWP (maximum working pressure)
7 Length data
8 Electronic version (output signal)
9 Cable entry
10 Supply voltage
11 Min./max. span
12 Wetted materials
13 ID number of notified body with regard to ATEX (optional)
14 ID number of notified body with regard to Pressure Equipment Directive (optional)
15 Approval-specific information
16 Degree of protection
Devices for use in hazardous areas are fitted with an additional plate.
P01-xMx5xxxx-18-xx-xx-xx-002
Fig. 4: Additional nameplate for devices for use in hazardous areas, or devices with a CSA and FM approval
1 Approval-specific information
Pmax
Tmax
for oxygen service
Bei Sauerstoffeinsatz/
3
1
2
1
4
2
3
5
6
7
8
9
11
10
12
13
14
15
15
16
002758-–
cable entry:
L=
Span
Mat.
002757-–
p
Ordercode:
Orderident:
Ser.-No.:
MWP
D-79689 Maulburg
Made in Germany,
1
1
1
1
1
002760
-
–
Install per drawing
Dat.:
002759
-
–
Ta>60°C:
t>80°C
