Cerabar M, Deltabar M, Deltapilot M / 4...20 mA HART Appendix
Endress+Hauser 115
Empty calib. (028)
Empty calib. (011)
Entry
Enter the output value for the lower calibration point (container empty).
The unit defined in "Output unit" must be used.
!
Note!
• In the case of wet calibration, the level (container empty) must actually be available.
The associated pressure is then automatically recorded by the device.
• In the case of dry calibration, the level (container empty) does not have to be available.
The associated pressure has to be entered in the "Empty pressure (029)" parameter for
the "In pressure" level selection. The associated height has to be entered in the "Empty
height (030)" parameter for the "In height" level selection.
Factory setting:
0.0
Empty pressure (029)
Entry/display
Enter the pressure value for the lower calibration point (container empty).
See also "Empty calib. (028)".
Prerequisite
• "Level selection" = In pressure
"Calibration mode" = Wet (display only), Dry (entry)
Factory setting:
0.0
Empty height (030)
Entry/display
Enter the height value for the lower calibration point (container empty). Select the unit
via the "Height unit (026)" parameter.
Prerequisite:
• "Level selection" = in height and "Calibration mode" = wet (display only) , Dry (entry)
Factory setting:
0.0
Full calib. (031)
Full calib. (012)
Entry
Enter the output value for the upper calibration point (container full).
The unit defined in "Output unit" must be used.
!
Note!
• In the case of wet calibration, the level (container full) must actually be available. The
associated pressure is then automatically recorded by the device.
• In the case of dry calibration, the level (container full) does not have to be available.
The associated pressure has to be entered in the "Full pressure (030)" parameter for the
"In pressure" level mode. The associated height has to be entered in the "Empty height"
parameter for the "In height" level selection.
Factory setting:
100.0
Full pressure (032)
Entry/display
Enter the pressure value for the upper calibration point (container full).
See also "Full calib.".
Prerequisite
• "Level selection" = in pressure and "Calibration mode" = wet (display only), Dry (entry)
Factory setting:
Upper-range limit (URL) of the sensor
Full height (033)
Entry/display
Enter the height value for the upper calibration point (container full). You select the unit
via the "Height unit" parameter.
Prerequisite:
• "Level selection" = in height and "Calibration mode" = wet (display only), Dry (entry)
Factory setting:
Upper-range limit (URL) is converted to a height unit
Density unit (127)
Display
Displays the density unit. The measured pressure is converted to a height using the
"Height unit", "Density unit" and "Adjust density" parameters.
Factory setting:
•g/cm
3
Adjust density (034)
Entry
Enter the density of the medium. The measured pressure is converted to a height using
the "Height unit" and "Adjust density" parameters.
Factory setting:
1.0
Parameter name Description
