Appendix Cerabar M, Deltabar M, Deltapilot M / 4...20 mA HART
100 Endress+Hauser
10 Appendix
10.1 Overview of operating menu
!
Note!
All the parameters are listed in the following table. The page number refers to where a description
of the parameter can be found.
Level 1 Level 2 Level 3 Level 4 Direct
access
Page
Parameters in italics are read-only parameters and cannot be edited. Specific settings, such as the measuring mode, dry or wet calibration, or hardware locking,
determine whether these parameters are displayed.
Language 000 109
Display/operat. Display mode 001 109
Add. disp. value 002 109
Format 1st value 004 110
Setup Lin./SQRT switch (Deltabar M) 133 110
Measuring mode
Measuring mode (read only)
005
182
110
Switch P1/P2 (Deltabar M) 163 112
High pressure side (Deltabar M)
High pressure side (read only)
006
183
112
Press. eng. unit 125 111
Corrected press. 172 113
Pos. zero adjust (Deltabar M and relative pressure sensors)
Calib. offset (absolute pressure sensor)
007
192
111
111
Max. flow ("Flow" measuring mode) (Deltabar M) 009 118
Max. pressure flow ("Flow" measuring mode) (Deltabar M) 010 119
Empty calib. (Level measuring mode and "Calibration mode" = wet) 011 115
Full calib. (Level measuring mode and "Calibration mode" = wet) 012 115
Set LRV (Pressure measuring mode and flow linear) 013 121
Set URV (Pressure measuring mode and flow linear) 014 121
Damping switch (read only) 164 111
Damping
Damping (read only)
017
184
111
Flow ("Flow" measuring mode) (Deltabar M) 018 119
Level before lin (Level measuring mode) 019 116
Pressure af. damp 111 113
Extended setup Code definition 023 108
Device tag 022 109
Operator code 021 108
Level (Level measuring mode) Level selection 024 114
Output unit 025 114
Height unit 026 114
Calibration mode 027 114
... ... ...
Empty calib.
Empty calib.
028
011
115
