Appendix Cerabar M, Deltabar M, Deltapilot M / 4...20 mA HART
118 Endress+Hauser
Norm. flow unit (046)
Selection
Select norm flow unit.
When a new flow unit is selected, all flow-specific parameters are converted and
displayed with the new unit within a flow type. When the flow type is changed,
conversion is not possible.
Prerequisite:
• "Flow type" (044) = Volume norm. cond.
Options:
• Nm3/s, Nm3/min, Nm3/h, Nm3/d
Factory setting:
Nm
3
/s
Std. flow unit (047)
Selection
Select standard flow unit.
When a new flow unit is selected, all flow-specific parameters are converted and
displayed with the new unit within a flow type. When the flow type is changed,
conversion is not possible.
Prerequiste:
• "Flwo type" (044) = Volume std. cond.
Options:
• Sm3/s, Sm3/min, Sm3/h, Sm3/d
• SCFS, SCFM, SCFH, SCFD
Factory setting:
Sm
3
/s
Flow unit (048)
Selection
Select volume flow unit.
When a new flow unit is selected, all flow-specific parameters are converted and
displayed with the new unit within a flow type. When the flow type is changed,
conversion is not possible.
Prerequisite:
• "Flow type" (044) = Volume process cond.
Options:
• dm3/s, dm3/min, dm3/h
• m3/s, m3/min, m3/h, m3/d
• l/s, l/min, l/h
• hl/s, hl/min, hl/d
• ft3/s, ft3/min, ft3/h, ft3/d
• ACFS, ACFM, ACFH, ACFD
•ozf/s, ozf/min
• Gal/s, Gal/min, Gal/h, Gal/day, MGal/d
• I. Gal/s, I. Gal/min, I. Gal/h
• bbl/s, bbl/min, bbl/h, bbl/d
Factory setting:
m
3
/s
Max. flow (009)
Entry
Enter maximum flow of primary element.
See also layout sheet of primary element. The maximum flow is assigned to the maximum
pressure which you enter via the "Max. pressure flow" (010) parameter.
!
Note!
Use the "Linear/Sqroot" (055) parameter to specify the current signal for the "Flow"
measuring mode. The following applies for the "square root" setting:
If you enter a new value for "Max. flow" (009), the value for "Set URV" (057) is also
changed. Use the "Set URV" (057) parameter to assign a flow to the upper current value.
If you want to assign the upper current value a value other than that for "Max. flow"
(009), you must enter the desired value for "Set URV" (057).
Factory setting:
100.0
Parameter name Description
